Features
- Create, connect, and communicate with Matter® compatible devices using Arduino as the software layer for rapid prototyping
- Uses Thread for IoT mesh networking communication in a highly compact form factor
- Integrated MGM240SD22VNA boasts a 32-bit Arm® Cortex®-M33 processor optimized for complex calculations and signal processing in power-sensitive IoT applications
- Leverage dual-mode connectivity, integrating both IEEE 802.15.4 (Thread) for mesh networking and BLUETOOTH Low Energy for short-range communication
- No external debugging device is needed, connect the board to the computer over USB and have access to a SWD interface
- Designed as an ultra-low power board, being the perfect solution for IoT battery-powered applications
- With a length of 45mm and a width of 18mm, the Nano Matter maintains a tiny footprint of the well-known Nano family, allowing easy upgrades for existing projects
- Protect projects with the industry-leading suite of security features from Silicon Labs escalating Internet of Things (IoT) threats
Applications
- Internet of Things (IoT)
- Home automation
- Professional automation
- Environmental monitoring
- Climate control
Pinout
Block Diagram
Power Supply
